DAC-8

DAC-8 is a 10-bit Digital to Analog Converter (DAC) board with I2C 2-wire interface. DAC-8 has 8 analog output channels.

Documents Peripherals

DAC-8 - 8-bit Digital to Analog Converter boards with I2C 2-wire interface

Features

10-bit, 8 channels DAC using AD5315 micro-power IC with 6 uS setting time
Two 6-pin terminal blocks and one 4-pin terminal block for 8 analog outputs
I2C slave device
Onboard 4.096V precision reference source powered from an external 5VDC
Terminal blocks for DAC outputs and ground returns
