Features

• Octavo OSD32MP157C-512M-IAA CPU Module running at 650 MHz
• Dual ARM® Cortex® -A7 core and one Cortex®-M4
• 512 Megabytes of RAM, 32 Megabytes of QSPI Flash, microSD (optional)
• Open system
• OpenWRT Linux
• Debian and other Linux variants supported
• WiPOM software option for management, data acquisition and logging
• Over the air and local upgrade
• Software can be upgraded remotely
• Cloud connectivity, support for many protocols
• USB host interface allows interfacing with off-the-shelf USB dongles. Examples: USB Bluetooth, USB ZigBee, USB RS485
• Supports all variants of Nimbelink Skywire™
• Plug-and-play operation with Linux, Windows 10 and 11 host
• Customer can use any compatible antenna without requiring re-certification
• Optional LTE antennas
• Communication Method: USB or Ethernet (100Mbps)
• Type A high-retention USB Host connector
• User accessible microSD socket
• 4-pin latching connector for power
• 2 Analog or 2 Digital inputs on power connector, software configurable
• Optional DC cable or AC adapter
• Supply voltage: 8-30VDC
• Power consumption: 1 Watt typical (no transmit)
• Temperature range: -40°C to +85°C
• Warranty Period: 3 years
