CG9101-nanoWiPOM


A PLC-like co-processor board forremote monitoring and logging of voltages, currents, frequencies and many other physical parameters

CG9101-nanoWiPOM - Cloudgate version of nanoWiPOM board
Part No. Description Price Stock
CG9101-nanoWiPOM Cloudgate version of nanoWiPOM board $179 2

Features


  • Fast Cortex processor
  • 32MB log memory, expandable to 32GB with microSD
  • Status LED's ( Red, Yellow, Green )
  • RS232 port
  • RS485 as MODBUS master or slave
  • Device USB and USB On-The-Go
  • 2 Analog Inputs, selectable as 4-20mA, 0-5V or 0-10V
  • 4 Digital Inputs, 2 Digital Outputs ( High current )
  • All I/O and serial ports on 25-pin DSUB connector
  • Powers from CloudGate
  • Low power consumption: Under 100mA
  • WRTU software simplifies setting up
  • Optional DIN-rail terminal block breakout board
